This brake rotors is intended for 2016-2023 Mazda CX-9. Review the fitment details before ordering.
- Brand: TRQ
- Manufacturer part number: BRA78567
- Catalog product code: 1ABFS05583
- Vehicle makes: Mazda
- Vehicle models: CX-9
- Model years: 2016-2023
- Position: Rear, Driver Side, Passenger Side
Product details: Kit Includes: (1) Rear Passenger Side Brake Rotor (1) Rear Driver Side Brake Rotor Overall Height: 1.77 in 45 mm Mounting Bolt Hole Diameter: 13 mm 0.51 in Discard Thickness: 0.35 in 9 mm Stud/Lug Hole Diameter: 13 mm Solid Or Vented Type Rotor: Solid Brake Rotor Venting Type: Solid Quantity: 2 Piece Material: Cast Iron Center Hole Diameter: 2.68 in Wheel Lug Count: 5 Lug Mounting Bolt Hole Circle Diameter: 4.49 in 114 mm Rust Resistant Coating: No Conventional Or Drum-In-Hat Type Rotor: Conventional ABS Tone Ring Included: No Brake Rotor Diameter: 12.8 in. (325mm) Surface Type: Smooth Outside Diameter: 325 mm 12.8 in Stud/Lug Hole…
Fitment can vary by trim, drivetrain, engine, production date, and installation position. Compare the product details with the part being replaced before purchase.
